Product : Articulated Arm Tapping Machine

It is a unique tapping machine with an articulated arm which helps in tapping a hole anywhere within the working area. This machine is having a range to tap holes up to M 20 in steel and M 24 in aluminum.

It consists of a specially designed arm carrying pneumatic reversible tapping motor which will tap thought holes as well as blind holes.

Orbital tapping machine is available in two models with various arm-lengths to suits your requirements.

A versatile machine which can be used for:

Tapping
Retapping
Inserting helicoils
Chamfering
Reaming
Countersinking etc.

Model		Tapping Capacity max.		No load speed RPM	Air pressure in Kg / cm²	Air Reqd. in CFM	Torque in Kg.m	Reach in mm.
Model		Steel	Aluminium	No load speed RPM	Air pressure in Kg / cm²	Air Reqd. in CFM	Torque in Kg.m	Reach in mm.
OS	T 10	M 10	M 12	320	5.5	28	2.5	1000
OS	T 20	M 20	M 24	180	5.5	28	8.0	1000


	Easy forward /reverse grip This facilitates operator for easy forward / reverse operation of motor with simple 'twist'.

	Depth control mechanism This mechanism has been categorically incorporated to tap blind holes as well as to tap holes at preset depth. This special feature helps in avoiding tap breakage as well as thread damage.

	Tension adjusting knob This is a customer friendly feature incorporated to assist the operator to adjust the force he has to apply while locating the tapping head in line with the hole.

	Quick change tapchuck This helps in holding various tap holders firmly and saves time in changeover.
